GJYXFCH 1core 2 Core Single-Mode Self-Supporting FTTH Drop Fiber Optic Cable with Anatel Certification

Product Description

GJYXFCH 1core 2 Core Single-Mode Self-Supporting FTTH Drop Fiber Optic Cable with Anatel Certification

--Can be installed without shutting off the power

---Light weight and small diameter reducing the load caused by ice and wind and the load on towers and backprops
---Large span lengths
---Good performance of tensile strength and temperature
--- Arc-erosion-resistant AT jecket
---The design life span is 30 years
---Package :4-5 km/ wooden drum

Cable Performance Parameter
Span meter	200	300	400
Related Strength Tension(RTS)	17.5 kn	20.6 kn	28 kn
Max Allowable Tension(MAT)	6.9 kn	8.2 kn	11.5 kn
Allowable Crush Resistance	Long Term: 1100 n/100mm	Long Term: 1100 n/100mm	Long Term: 1100 n/100mm
Allowable Crush Resistance	Short Term: 2200 n/100mm	Short Term: 2200 n/100mm	Short Term: 2200 n/100mm
Minimum Bending Radius	Operating: 220 mm	Operating: 220 mm	Operating: 220 mm
Minimum Bending Radius	Installlation: 360 mm	Installlation: 360 mm	Installlation: 360 mm
Temperature Range	Operating: -40 /+70ºC	Operating: -40 /+70ºC	Operating: -40 / +70ºC
Temperature Range	Installlation: -15 / +60ºC	Installlation: -15 / +60ºC	Installlation: -15 / +60ºC
Out Sheath Material	Electrical Resistance AT (Borealis material 6081) Sheath
Note	ice accretion 5MM,weed speed:30M/S
