UL1331 24AWG Oil Resistant High Temperature Electric Wire for High Power Lamps
UL1331 24AWG Oil Resistant High Temperature Electric Wire for High Power LampsPRODUCT DESCRIPTION:Rated Temperature150ºCConductor Nickle plating or tin/bare copper conductorStandardUL Subject758,UL1581,C22.2Application For general purpose internal wiring of appliance AWGNO.of Cond(mm)Conduc......
Send Inquiry
Product Description
UL1331 24AWG Oil Resistant High Temperature Electric Wire for High Power Lamps
PRODUCT DESCRIPTION:
PRODUCT DESCRIPTION:
| Rated Temperature | 150ºC | Conductor | Nickle plating or tin/bare copper conductor |
| Standard | UL Subject758,UL1581,C22.2 | Application | For general purpose internal wiring of appliance |
| AWG | NO.of Cond (mm) | Conductor resistance 20ºC (Ω/KM) | Conductor Dia (mm) | Insulation Thickness (mm) | Overall Diameter (mm) | ||
| Nom. | Min. | Nom. | Tol. | ||||
| 10 | 37/0.42 | 3.54 | 2.94 | 0.50 | 0.45 | 3.94 | ±0.15 |
| 12 | 37/0.374 | 5.64 | 2.62 | 0.50 | 0.45 | 3.62 | ±0.15 |
| 14 | 19/0.361 | 8.96 | 1.85 | 0.50 | 0.45 | 2.90 | ±0.10 |
| 16 | 19/0.287 | 14.60 | 1.50 | 0.50 | 0.45 | 2.50 | ±0.10 |
| 18 | 19/0.235 | 23.20 | 1.18 | 0.50 | 0.45 | 2.20 | ±0.10 |
| 20 | 19/0.19 | 36.70 | 0.95 | 0.50 | 0.45 | 1.95 | ±0.10 |
| 22 | 19/0.15 | 59.40 | 0.76 | 0.50 | 0.45 | 1.75 | ±0.10 |
| 24 | 7/0.20 | 94.20 | 0.61 | 0.50 | 0.45 | 1.60 | ±0.10 |
| 26 | 7/0.16 | 150.00 | 0.48 | 0.50 | 0.45 | 1.50 | ±0.10 |
| 28 | 1/0.32 | 227.00 | 0.320 | 0.50 | 0.45 | 1.32 | ±0.10 |
| 30 | 1/0.254 | 361.00 | 0.254 | 0.50 | 0.45 | 1.26 | ±0.10 |
