AWG22 UL2835 Tinned Copper Coated Wire PVC Control Cable
AWG22 UL2835 Tinned Copper Coated Wire PVC Control Cable PRODUCT DESCRIPTION:Rated temperature: 60 ºCRated voltage: 30VAccording to the standard: UL758,UL1581,CSA C22.2 No.210.2Stranded,tinned or bare copper, or tinsel conductor Color-coded PVC or PE or PP insulationTinned or bare Copper d......
Send Inquiry
Product Description
AWG22 UL2835 Tinned Copper Coated Wire PVC Control Cable
Q1: Can I get free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6:Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation
4. Professional service
WHY CHOOSE US
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R& D team
3. Equipment
With completive testing equipment.
4. Quality
UL/ CE/ FCC/ RoHS/ Reach certificate
- PRODUCT DESCRIPTION:
★Rated temperature: 60 ºC
★Rated voltage: 30V
★According to the standard: UL758,UL1581,CSA C22.2 No.210.2
★Stranded,tinned or bare copper, or tinsel conductor
★Color-coded PVC or PE or PP insulation
★Tinned or bare Copper drain wire
★Tinned or bare Copper wire braid shield available
★PVC jacket
★Passes UL VW-1 & CSA FT1 vertical flame test
★Uniform insulation thickness to ensure easy stripping and cutting
★Environmental testing pass RoHS
★For internal wiring in Class 2 circuits of electronic equipment or TV game machine data transmission
| Cores | Conductor | Insulation | Drain Wire | Overall Shield | Jacket | Maximum Resistance at 20ºC Ω/km | |||||
| AWG | No./mm | Dia. | Nom.Thick. | Nom.Dia. | No./mm | Material | Spiral No./mm | Nom.Thick. | Nom.Dia. | ||
| mm | mm | mm | mm | Braid No./No./mm | mm | mm | |||||
| 4 | 28 | 7/0.127 | 0.38 | 0.22 | 0.82 | - | AL | 57/0.1 | 1.00 | 4.30 | 223.00 |
| 4 | 22 | 17/0.16 | 0.76 | 0.22 | 1.20 | 17/0.16 | AL | - | 0.45 | 4.00 | 57.50 |
| 5 | 28 | 19/0.08 | 0.40 | 0.20 | 0.80 | - | PAPER | 16/6/0.12 | 0.88 | 4.80 | 220.00 |
| 6 | 28 | 7/0.127 | 0.38 | 0.22 | 0.82 | - | AL | 79/0.1 | 0.68 | 4.30 | 223.00 |
| 7 | 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 7/0.16 | - | 75/0.12 | 0.90 | 5.00 | 223.00 |
| 7 | 32 | TINSEL | 0.56 | 0.22 | 1.00 | 7/0.16 | - | 16/7/0.1 | 0.75 | 5.20 | 1000.00 |
| 8 | 28 | 19/0.08 | 0.40 | 0.23 | 0.86 | - | PAPER | 24/5/0.1 | 0.74 | 4.80 | 220.00 |
| 9 | 28 | 7/0.127 | 0.38 | 0.22 | 0.82 | - | PAPER | 81/0.12 | 0.74 | 4.90 | 223.00 |
| 10 | 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 7/0.16 | AL | - | 0.57 | 5.00 | 223.00 |
