Product Description

ASTM Aluminium Alloy Conductor AAAC (Alliance)

Overhead conductor,Bare conductor AAAC conductor used as overhead conductor referred to have higher strength but lower conductivity than pure aluminum.being lighter, alloy conductors can sometimes be used to advantage in place of the more conventional ACSR;having lower breaking loads than the latter,their use becomes particularly favourable when ice and win loadings are low.

AAAC (BS3242 Standard)

Code	Nominal size	Wire No/diameter	Complete diameter	Total cross-area	Conductor weight	Cable breakdown load	Max.DC resistance 20	Packing length
-	mm²	Nos./mm	Mm	mm²	Kg/Km	daN	Ohm/Km	Meter+5%
Box	15	7/1.47	5.55	18.8	51	529	1.749	3000
Acacia	20	7/1.85	6.24	23.9	65	670	1.384	2500×2
Almond	25	7/2.08	7.02	30.1	82	844	1.094	2500×2
Cedat	30	7/2.34	7.62	35.5	97	995	0.9281	3200
Fir	40	7/2.77	8.85	47.8	131	1340	0.6680	2800
Hazel	50	7/2.95	9.90	59.9	164	1680	0.5498	2700
Pine	60	7/3.30	10.83	71.7	196	2010	0.4595	2350
Willow	75	7/3.91	12.12	89.8	246	2517	0.3669	2850
Oak	100	7/4.45	13.95	118.9	325	3330	0.2769	2000
Mulberry	125	19/3.18	16.9	151.1	415	4230	0.2190	2900
Ash	150	19/3.48	14.4	180.7	497	5060	0.1830	2300
Elm	175	19/3.76	18.8	211.0	580	5910	0.1568	2900
Poplar	200	37/2.87	20.09	239.0	660	6700	0.1387	2300
Sycamore	250	37/3.23	22.61	303.0	835	8490	0.1094	2000
Upas	300	37/3.53	24.71	362.1	998	10150	0.09155	2500
Yew	400	37/4.06	28.42	479.9	1323	13450	0.06908	2000
