14AWG 16AWG 18AWG Silikon Kabel High Temperature Silicone Cable Wire

Product Description

Composition
1.Conductor:Tinned copper or bare copper
2.Insulator:Silicone rubber

Description
1. Nominal Voltage: 600V
2. Temperature Range: -60°C to +200°C
3. O.D.Allowance: ±0.10mm
4.Color: Black-Brown-Red-Orange-Yellow-Green-Blue-Purple-Gray-White-Transparent-Yellow/green,etc
5.Application:14awg silicone wire applied to insustry,electrical household appliances,lamps,electronic equipment,etc

Features
1.Superior dielectric properties;
2.Resistance to high temperatures, moisture, and oil;
3.Low eccentricity,prevent breakdown and safety protection;
4.The ability to match your flammability rating requirements, including flame retardancy, low smoke, and low toxicity;
5.The ability to meet international industry standards,with eco-friendly material.

AWG	Spec	Conductor		Insulation Thinkness		Wire Diameter		Max Resistance 20⁰C
AWG	Spec	Structure	Diameter	Nominal	Min	Nominal	Tolerance	Max Resistance 20⁰C
NO.	mm2	mm	mm	mm	mm	mm	mm	Ω/KM
26	0.128	7/0.16	0.48	0.76	0.69	2.00	±0.10	148
24	0.205	7/0.20	0.6	0.76	0.69	2.15	±0.10	93
22	0.324	7/0.25	0.75	0.76	0.69	2.30	±0.15	55
20	0.519	7/0.31	0.96	0.76	0.69	2.50	±0.15	34.6
18	0.823	7/0.39	1.20	0.76	0.69	2.75	±0.20	21.8
16	1.31	7/0.49	1.47	0.76	0.69	3.00	±0.20	13.7
14	2.08	41/0.254	1.90	0.76	0.69	3.45	±0.25	8.62
12	3.31	19/0.49	2.50	0.76	0.69	4.05	±0.25	5.38
26	0.128	1/0.42	0.42	0.76	0.69	1.95	±0.10	142
24	0.205	1/0.52	0.52	0.76	0.69	2.05	±0.10	89
22	0.324	1/0.65	0.65	0.76	0.69	2.20	±0.15	54.3
20	0.519	1/0.82	0.82	0.76	0.69	2.35	±0.15	33.9
18	0.823	1/1.05	1.05	0.76	0.69	2.60	±0.20	21.4
16	1.31	1/1.30	1.30	0.76	0.69	2.85	±0.20	13.5

PDCA with ISO Management System
Plan - Do - Check - Act (PDCA) cycle is the foundation of all ISO management system standards. The cycle ensures development, continuous improvement and control of the quality management system. The standard offers multiple benefits to an organisation such as:
1.Enhanced customer satisfaction.
2.Consistency in the delivery of your product or service.
3.Improved communication, planning and administration.
4.Enhanced business performance.
5.Better cost management.
6.Increased credibility and competitiveness price.
7.UL approve :Certified products,More security!

Step Three: Ensure All Products Passed Testing
Accordance with the standards of production and inspection processes, pre-production material sampling,real-time monitoring of production, detection of finished products,in order to ensure stability of 1.5mm silicone wire quality.

Luxing Cable Factory Mainly Produce

300/500V 450/750V electrical wire	AAC conductor
600/1000V PVC insulated cable	AAAC conductor
600/1000V XLPE insulated cable	ACSR conductor
1.8/3KV to 26/35KV power cable	OPGW
Armored underground cable	ABC cable
Control cable and instrumentation cables	Rubber cable
