Low Db Loss Combination Coaxial Cable Rg59

Product Description

1. CCTV camera visual extension cable
2. Easy use
3. Anti-aging capability
4. Soft and flexible
5. RoHS/CE is available

Specifications
5C *(0.81CU+3.7 FPE+24*7*0.12*95% TC BRAIDING+6.15 PVC ) + 18.923 TPE

IMPEDENCE: 75+/-3OHMS
CAPACITANCE: 58PF/M

Note:
1) Center Conductor: Tinned Copper, Bare Copper, and Copper Clad Steel available;
2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, and double non-bonded Al-foil are available;
3) Braiding Wire: AL-Mg, Bare Copper and Tinned Copper available;
4) Braiding Wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15mm available;
5) Braiding Coverage: Between 30- 95% available
6) Jacket Color: White, black, etc.

Packaging:
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's requirement;
2) Inner Packing: Wooden reel, Plastic reel, and Paper reel available;
3) Outer Packing: Carton Box, Pull out Box, Pallet available;
4) Other packing available according to client's requirement.

Product Origin: China
Brand Name: RuiFeng or OEM
Productivity: 300, 000Km/Year
Price Terms: FOB, CIF, CFR
Payment Terms: L/C, T/T, Western Union
Shipping Date: Generally within 15days

#Coaxial Cables:
1) RG Series Coaxial Cable: RG58, RG59, RG6, RG7, RG11, etc;
2) Network Cables: LAN Cable CAT3, LAN Cable CAT5;
3) Combined Cable: Siamese Cables: RG59+2C, RG6+2C, etc.

#Applications:
1) CATV-community antenna television;
2) CCTV-closed-circuit television;
3) DBS-direct broadcasting satellite.

Main products:
1) RG series Coaxial Cable: Rg59, RG6, rg7, rg8, rg11, RG58, rg142, rg174, rg178, rg179, rg213, rg214, rg316, rg393, rg402, etc.;

2) JIS series Coaxial Cable: 1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, 3D-FB, 5D-FB, 8D-FB, 10D-FB, etc.;

3) Vatc series Coaxial Cable: 17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8;

4) TRUNK Cable: P3 412, 500, 540, 625, 750, 850;

5) LMR SERIES: LMR200, LMR400, LMR600;

6) Network Cables: LAN Cable CAT3, LAN Cable CAT5, LAN Cable CAT5e, LAN Cable CAT6, LAN Cable CAT7;

7) Combined Cable: Siamese Cables: RG59+2C, RG6+LAN cable, RGB5CRG59, BT3002.

Data	RG59	RG59-Tri	RG59-Quad
Impedance(ohm)	75± 3	75± 3	75± 3
Capacitance(pF/m)	52± 2	52± 2	52± 2
Velocity Ratio	85%	85%	85%
Insulation Resistance(MΩ /km)	5000	5000	5000
Return Loss(dB)
1-1000MHz	≥ 23dB	≥ 23dB	≥ 23dB
1000-3000MHz	≥ 20dB	≥ 20dB	≥ 20dB
Attenuation[@20° C68° F]
Frequency(MHz)	5 50 200 400 800 1000 1350 1750 2150 3000
Nom Value(dB/100m)	1.7 5.2 10.2 14.8 22.5 25 30.5 33.5 37.5 46.5
Screening attenuation
1-1000MHz	≥ 90dB	≥ 100dB	≥ 110dB

RG6 Coaxial Cable Introduce and Parameter: 75 Ohm
		SHIELD SHIELD	TRI-SHIELD	QUAD-SHIELD
CONDUCTOR	MATERIAL	BC/CCS	BC/CCX	BC/CCX
CONDUCTOR	Nom. Dia	18AWG	18AWG	18AWG
DIELECTRIC	MATERIAL	Foamed PE	Foamed PE	Foamed PE
DIELECTRIC	Nom. Dia	4.57mm	4.57mm	4.57mm
SHIELD	MATERIAL	AL Foil+AL Braiding	AL-Foil+Braiding of AL +AL-Foil	(AL-Foil+Braiding of AL)*2
	COVERAGE	40%-90%	40%-90%	40%/60%
	METERIAL	PVC/PE	PVC/PE	PVC/PE
JACKET	Nom. Thick.	0.80mm	0.80mm	0.86mm
JACKET	Nom. Dia	6.91mm	6.91mm	6.91mm

Coaxial Cable	Conductor	No. and Nominal Diameter of Strands#/mm	Sheathed	Nominal Overall Diameter(mm)
RG6	TCW(Tinned Copper Wire)	1/1.02	PVC	6.5
RG11	TCW	7/0.40	PVC	10.30
RG58	TCW	19/0.18	PVC	4.90
RG59	TCW	1/0.58	PVC	6.15
